BMS 8-24S 80A LFP SMART CAN JK (BD4A24S8PCY) (7afb)

JK LFP Smart BMS CAN 8-24S 80A (BD4A24S8PCY)

Product Data Sheet

• •Number of Battery Strings(Lifepo4): 8S-24S
• •Balance Current: 0.6A
• •Continuous charging current: 80A
• •Continuous discharging current: 80A
• •Voltage Acquistion Accuracy: -+5mV
• •Single Cell Voltage Range: 1.5V

The BMS LFP 8-24S 80A SMART CAN JKBM (BD4A24S8PCY) is an advanced Battery Management System designed for 8 to 24 series cells in lithium iron phosphate (LiFePO4) battery packs. It supports a continuous discharge current of 80A, making it ideal for high-power applications such as electric vehicles, solar energy storage, and backup power systems. The BMS incorporates SMART CAN communication, allowing for seamless integration and real-time monitoring through the CANBUS protocol. It provides critical protection features, including overcharge, over-discharge, overcurrent, short circuit, and temperature management. Additionally, it includes active cell balancing to ensure uniform voltage across cells, optimizing battery performance and extending its lifespan. This system offers reliable and efficient battery management with advanced monitoring capabilities for various high-demand applications.
