BMS LFP 20S 100A SMART CAN DALY (42f2)

DALY Smart BMS LiFePO4 20S 60V 100A Common port with Balance

Product Data Sheet Product Data Sheet

The DALY SMART BMS LFP 20S 100A is engineered for professionals seeking reliable control over 20S (64V nominal) LiFePO4 battery packs. This Battery Management System is capable of handling a continuous current of 100A, making it perfect for high-load applications including electric vehicles (EVs), solar energy storage systems, industrial backup systems, and off-grid power solutions.

Specifications

• •Battery Configuration: Smart BMS LiFePO4 20S 60V 100A Common port with Balance
• •Continuous Discharge Current: 100A
• •Over-Voltage Protection: 3.8V
• •Charge Current: 50A
• •Charge Voltage: 73V
• •Short Circuit Protection: Yes, with auto recovery
• •Temperature Protection: Over-temperature and under-temperature protection
• •Features: Overcurrent, overcharge, over-discharge, and temperature protection

Key Benefits

• •Power Delivery Up to 100A: Designed to handle heavy-duty charge and discharge operations, making it ideal for high-capacity power systems.
• •Advanced Battery Protection: Ensures protection against overcharge, over-discharge, short circuits, overheating, and overcurrent—extending the life of your LiFePO4 battery pack.
• •Smart Communication: Features CAN Bus and UART protocols, allowing seamless integration with monitoring software and battery management dashboards.
• •Reliable Thermal Control: Embedded with temperature sensors (NTC) and heavy copper PCB for heat regulation.

Applications

• •Electric Two-Wheelers, E-Rickshaws & AGVs
• •Powerwalls and Lithium Battery Banks
• •Solar Off-grid Storage Systems
• •Industrial Backup UPS Solutions
• •DIY and Commercial Battery Pack Integrations

With the wide application of lithium batteries in the lithium battery industry, requirements for high performance, high reliability and high cost performance are also put forward for battery management systems. This product is a BMS specially designed for lithium batteries. It can collect, process and store the information and data of the battery pack in real time during use to ensure the safety, availability and stability of the battery pack.

Using professional high-current trace design and technology, it can withstand the impact of ultra-large current. The appearance adopts the injection molding sealing process to improve moisture resistance, prevent the oxidation of components, and prolong the service life of the product. dust proof, shockproof, anti-squeezing and other protective functions. There are complete overcharge, over-discharge, over-current, short circuit, equalization functions. The integrated design integrates acquisition, management, communication and other functions into one
