K-TECH Lithium-ion Rechargeable Cell 34145 LiFePO4 3.2V 15000 mAh

K-TECH LiFePO4 CELL 15000mAh 3.2V 34145 - High Performance & Long Life

Product Data Sheet

The K-TECH LiFePO4 CELL 34145 is a high-capacity 15Ah lithium iron phosphate (LiFePO4) battery with a 3.2V nominal voltage. Engineered for renewable energy storage, electric vehicles (EVs), industrial power applications, and solar backup systems, this battery offers exceptional cycle life, safety, and reliability.

Key Features

• •High Capacity & Voltage: 3.2V nominal voltage with a 15Ah (15000mAh) capacity for extended energy storage.
• •Long Cycle Life: Over 3,000 charge cycles, ensuring durability and cost-effectiveness.
• •Fast Charging & Discharging: Supports high charge/discharge rates for demanding applications.
• •Stable Performance: Low internal resistance for optimal energy output and efficiency.
• •Enhanced Safety: Built-in protection against overcharging, over-discharging, and short circuits.
• •Eco-Friendly: Free from hazardous heavy metals like lead and cadmium, making it environmentally safe.

Technical Specifications

• •

  Model: 34145

• •

  Nominal Voltage: 3.2V

• •

  Nominal Capacity: 15Ah (15000mAh)

• •

  Charge Voltage: 3.65V

• •

  Discharge Cut-off Voltage: 2.0V

• •

  Cycle Life: >3,000 cycles (80% DOD)

• •

  Max Charge Current: 1C (15A)

• •

  Max Discharge Current: 3C (45A)

• •

  Dimensions: 34mm x 145mm

• •

  Weight: Approximately 380g

Applications The K-TECH 15Ah 34145 LiFePO4 cell is widely used in various high-performance applications:

Electric Vehicles (EVs) & E-Bikes Provides stable and high-energy output for electric bicycles, scooters, and lightweight EVs.

Renewable Energy & Solar Power Storage Perfect for solar power storage systems, off-grid setups, and home battery banks, ensuring reliable backup power for renewable energy projects.

Industrial & Commercial Power Solutions Ideal for UPS systems, backup power, and industrial-grade energy storage solutions.

Power Tools & Custom Battery Packs Delivers consistent power output, making it suitable for cordless drills, electric screwdrivers, and industrial machinery.

Why Choose K-TECH LiFePO4 CELL 3.2V 15Ah 34145?

1. •Optimized for Energy Storage & EV Applications: Long-lasting and efficient for demanding energy solutions.
2. •Exceptional Safety: LiFePO4 chemistry ensures thermal stability, no explosion risk, and minimal self-discharge.
3. •Superior Cycle Life: Outperforms conventional lithium-ion batteries, reducing replacement costs.
4. •Eco-Friendly & Sustainable: 100% recyclable and compliant with global green energy initiatives.
