SB 50 WITH 12AWG WIRE-150MM
Minimum Quantity: 20 PCS
Currently out of stock. You can still request a quote — we'll reply with a lead time, or tell us to let you know the moment it lands.
Product Description
Designed for systems requiring up to 50 amps of continuous DC power, the SB50 connector offers robust, polarized, genderless design - allowing plug-to-plug compatibility without worrying about orientation. The 12AWG copper wires (150mm length) are pre-stripped and ready for soldering or crimping into your power system, minimizing time and ensuring a consistent connection.
Whether you’re creating battery charging ports, modular inverter panels, or DC bus bars, this compact 50A connector provides peace of mind with its reliable, heat-resistant build and versatile wire gauge.
Key Features
-
Plug & Play Simplicity Comes with factory-installed 12AWG wires (150mm length) - pre-cut, pre-tinned, and ready to use.
-
SB50 Standard Connector Industry-standard Anderson-style 2-pole connector rated for 50A, ideal for 12V to 60V DC systems.
-
Flame-Retardant & Impact-Resistant Housing Constructed from durable thermoplastic, suitable for heavy-duty applications in automotive, marine, and industrial fields.
-
Polarity-Safe Genderless Design Each SB50 connector mates with another of the same type, simplifying connections and inventory.
-
High-Purity Copper Terminals Silver-plated copper contacts ensure maximum conductivity and low resistance over time.
-
Compact Wire Length for Tight Spaces 150mm (15cm) wire tails are ideal for panel integration, battery banks, and confined enclosures.
Technical Specifications
| Attribute | Details |
|---|---|
| Connector Type | SB50 Anderson-style |
| Rated Current | 50 Amps Continuous |
| Voltage Rating | Up to 600V DC |
| Wire Gauge | 12 AWG (pre-attached) |
| Wire Length | 150mm |
| Terminal Type | Silver-plated copper contacts |
| Shell Material | Flame-retardant UL94 V-0 thermoplastic |
| Operating Temperature | -20°C to +105°C |
| Color | Grey housing with red/black wires |
Applications
- Lithium battery connectors
- E-bike and e-rickshaw power leads
- Solar inverter DC input/output
- Battery charging/discharging ports
- Modular UPS and backup systems
- DC power distribution boards
Package Includes
- 1 x SB50 Connector with 150mm 12AWG wire pre-installed
- Ready for installation into your power circuit
- Screws or crimp tools available separately upon request
SEO Tags & Keywords
Tags: SB50 plug with wire, Anderson connector 50A, 12 AWG DC cable connector, battery power plug 150mm, solar inverter DC plug, lithium battery terminal
Search Phrases:
- Buy SB50 connector with wire online
- Anderson plug 50A 12AWG
- DC connector 150mm wire length
- Battery quick disconnect 50 amp
- SB50 connector for solar and EV battery
Key Features
- Premium Quality
- Reliable Performance
- Long Service Life
- Certified Standards
Technical Specifications
- Model
- 80e5
- Product Name
- SB 50 WITH 12AWG WIRE-150MM
Applications
- Battery Packs
- Energy Storage
- Power Systems
Manufacturer
GLANNU INDUSTRIES
