JBD MASTER BMS JCHVB-M-100 HIGH VOLTAGE

MASTER BMS(JBD-JCHVB-M-100)HIGH VOLTAGE

Product Data Sheet

The JBD-JCHVB-M-100 High Voltage Master BMS is an intelligent High Voltage Battery Management System (Master Unit) designed to manage and monitor large lithium battery systems used in electric vehicles (EVs), Energy Storage Systems (ESS), commercial battery banks, and industrial power applications.

Working together with JBD Slave BMUs, the Master BMS provides centralized control, real-time battery monitoring, protection, communication, and fault diagnostics to ensure safe and reliable operation of high-voltage lithium battery packs. JBD's high-voltage architecture supports scalable battery systems and integrates seamlessly with commercial energy storage and EV applications.

Key Features

• •Model: JBD-JCHVB-M-100
• •High-voltage Master Battery Management System (BMS)
• •Supports communication with multiple JBD Slave BMUs
• •Compatible with LiFePO₄ (LFP) and Li-ion (NMC) battery packs
• •Advanced battery protection against:
  • •Overcharge protection
  • •Over-discharge protection
  • •Overcurrent protection
  • •Short-circuit protection
  • •Over-temperature protection
  • •Under-temperature protection
• •High-precision cell voltage, current, and temperature monitoring
• •Intelligent SOC (State of Charge) estimation and battery status management
• •Supports industrial communication interfaces such as CAN Bus and RS485 (configuration dependent)
• •Suitable for integration with inverters, PCS (Power Conversion Systems), and EMS (Energy Management Systems)
• •Industrial-grade design for continuous, reliable operation in high-voltage battery systems

Applications

High-Voltage Lithium Battery Packs

Used as the central controller for large lithium battery systems with multiple Slave BMUs.

Electric Vehicles (EVs)

Ideal for electric cars, buses, utility vehicles, commercial EVs, and other high-voltage battery packs.

Energy Storage Systems (ESS)

Suitable for solar energy storage, commercial battery banks, UPS backup systems, and Battery Energy Storage Systems (BESS).

Industrial Battery Systems

Used in high-capacity lithium battery installations for industrial equipment, automation systems, and backup power applications.

Renewable Energy Systems

Integrated with hybrid inverters, battery energy storage systems (BESS), microgrids, PCS, and EMS platforms.

The JBD-JCHVB-M-100 High Voltage Master BMS is the central control unit of a JBD high-voltage battery management system. It communicates with multiple Slave BMUs to provide intelligent monitoring, comprehensive protection, battery management, and industrial communication for high-voltage lithium battery packs used in EVs, energy storage systems, and industrial applications.
