DSF40 99V 40A Battery Tester – High-Precision Charge/Discharge Analyzer

Product Data Sheet

The DSF40 is a high-precision battery tester designed for comprehensive charge and discharge analysis of lithium-ion and lead-acid battery packs. With a wide voltage detection range from 9V to 99V and adjustable current settings up to 40A, it caters to various battery configurations, making it ideal for electric vehicle manufacturers, battery pack assemblers, and R&D laboratories.

Key Features

• •Voltage Range: 9V to 99V
• •Charge Current: 0.5A to 20A adjustable
• •Discharge Current: 0.5A to 40A adjustable
• •Operation Modes: Panel and Software control
• •Communication Port: LAN (TCP/IP protocol)
• •Input Power: AC 220V ±10%, 50Hz/60Hz
• •Display: High-definition LCD screen
• •Data Output: Excel format
• •Software Compatibility: Windows XP, 7, 8, 10
• •Cycle Index: 1 to 16 times
• •Protection Features: Power-down protection, reverse connection, over-temperature, over-voltage, short-circuit protection
• •Temperature Monitoring: Real-time battery temperature monitoring with automatic shutdown and alarm
• •Noise Level: <76 dB
• •IP Grade: IP20
• •Dimensions: 45 x 48 x 16 cm

Advanced Functionalities

• •Charge/Discharge Testing: Performs constant current and constant voltage charging, as well as constant current discharging.
• •Auto Cycle Testing: Supports automated charge-discharge cycles up to 16 times, useful for battery aging tests.
• •Data Analysis: Records voltage, current, capacity, and time intervals, providing detailed analysis and curve plotting.
• •Software Integration: Allows for remote operation, data sampling, test report generation, and analysis through dedicated software.
• •Multi-Device Management: One computer can manage multiple DSF40 units simultaneously via a network switch.
• •Modular Design: Facilitates easy maintenance and replacement of components.

Applications

• •Electric Vehicle Battery Testing: Ensures performance and reliability of EV battery packs.
• •Battery Manufacturing: Assists in quality control during battery production.
• •R&D Laboratories: Provides precise measurements for battery research and development.
• •After-Sales Service: Useful for battery maintenance and diagnostics.
